Technical Specifications for Grundfos SB 3-35 A:

• Maximum Flow Rate: 2.76 m³/h
• Head Range: 20.3 to 34 meters
• Rated Speed: 3400 RPM
• Liquid Type: Clean water
• Liquid Temperature Range: 0 to 40°C
• Optimal Liquid Temperature: 20°C
• Liquid Density: 998.2 kg/m³
• pH Range: 4 to 9
• Input Power (P1): 0.73 kW
• Rated Power Output (P2): 0.56 kW
• Frequency: 60 Hz
• Rated Voltage: 220–230V (Single Phase)
• Running Current: 3.3 A
• Starting Current: 26 A
• Starting Capacitor: 30 µF / 250 V
• Protection Class (IEC 34-5): IP68
• Insulation Class (IEC 85): F
• Integrated Motor Protection: Yes
• Cable Length: 15 meters
• Cable Type: H07RN-F 3G1
• Plug Type: Supplied without plug
• Ambient Temperature Range: -10 to 50°C
• Maximum Installation Depth: 10 meters
• Net Weight: 9.17 kg
• Gross Weight: 10 kg
• Particle Size Tolerance: Up to 1 mm

Key Applications:

• Clean Water Pumping: Ideal for wells, underground tanks, and reservoirs.
• Water Treatment & Fertigation: Effective in chemical dosing and controlled water delivery.
• Precision Irrigation: Supports drip, sprinkler, pivot, and lateral irrigation systems.
• Solar Agriculture: Compatible with solar-powered systems for livestock and crop irrigation.
• Rainwater Harvesting: Suitable for collecting and distributing harvested rainwater.
• Household Water Supply: Enhances water pressure and ensures consistent flow for residential use.
• Community Supply: Reliable for rural or off-grid water systems powered by solar energy.

Advanced Protection and Efficient Operation

Equipped with a built-in thermal protection system, this pump automatically shuts off if internal temperatures rise above safe limits, preventing damage to the motor. Once it cools to a safe temperature, it restarts automatically, ensuring continuous and safe operation under demanding conditions.

High-Performance Pumping in a Compact Design

Delivering a flow rate of 2.76 m³/h and a lifting range of up to 34 meters, this submersible pump is engineered for efficient and fast clean water delivery. Its 3400 RPM motor provides powerful suction and discharge performance, making it ideal for diverse residential and agricultural applications.

Durable Construction for Long-Term Use

Crafted by Grundfos SB 3-35 A , this pump is known for its exceptional build quality, corrosion-resistant materials, and energy-efficient performance. It offers long service life with minimal maintenance, making it a smart investment for reliable water management.
