SCALA2 Smart Water Pump ¾ HP – Technical Specifications and Key Features

Technical Specifications

• Suitable Fluid: Clean municipal water or drinking water
• Total Head (Lift Height): 15 to 45 meters
• Maximum Flow Rate (Qmax): 10 to 60 liters per minute
• Fluid Temperature Range: 4°C to 45°C
• Shaft Material: Stainless steel
• Inlet/Outlet Size: 1 inch
• Maximum Pressure: 10 Bar
• Power Output (P2): 0.75 Horsepower (¾ HP)
• Frequency: 50/60 Hz
• Voltage: 220 Volts
• Current: 2.8 Amps
• Motor Protection Rating: IPX4D
• Power Supply: Wired electric connection
• Pump Type: Surface pump
• Pump Body Material: Norly
• Ambient Temperature: Up to 45°C
• Certifications: CE, ASNZ4020
• Fan Material: Norly
• Motor Insulation Class: F

Why Choose the SCALA2 Smart Water Pump from Advanced Pumps Store?

• Automatic Operation: The pump works automatically by detecting faucet openings and closings, requiring no additional devices. It’s recommended to install it after the rooftop tank for better water pressure control.
• Stable Pressure Under Multiple Faucets: Maintains consistent pressure even when up to 8 faucets are open simultaneously.
• Easy Pressure Adjustment: Water pressure can be conveniently adjusted with a single button, ranging from 1.5 to 4.5 bar.
• Self-Priming: No need for manual refilling or air bleeding — the pump primes itself automatically.

SCALA2 Without External Foot Valve

No need for an external foot valve at the suction pipe’s end, which often gets damaged. The pump includes an internal foot valve at the suction inlet with built-in automatic protection against dry running (operating without water).

Quiet and Intelligent Operation

Operating noise is very low—just 47 decibels. The pump’s smart control panel detects faults, identifies their causes, and displays alerts. It also automatically shuts off if running continuously for more than 30 minutes (e.g., when a faucet is accidentally left open), preventing unnecessary wear.

Variable Speed for Maximum Energy Savings

Unlike traditional pumps that run at full speed regardless of demand, the SCALA2 adjusts its speed according to water usage. This variable-speed operation ensures optimal electricity savings. Featuring the world’s highest motor efficiency class IE5 and dual-frequency support (50/60 Hz), the pump is perfectly suited for use across the Gulf and Middle East.

Application Notes

The SCALA2 is ideal for villas when installed above the ground water tank, suitable for buildings up to 3 floors maximum.

Get Your SCALA2 Smart Pump Today!

Explore a wide range of pumps at Advanced Pumps Store and choose the perfect pump to meet your water pressure needs. Experience the perfect blend of quiet, smart, and energy-efficient water boosting.
